Mixer MKX16

● 16-channel design

● Two groups are equipped with independent output terminal, so that the connection is more flexible.

● 7-segment equalization, built-in 99 kinds of DSP effects

● Separate + 48V fantasy power switch

●MP3 large screen player (SD card support)

● High quality USB music player. With audio recording and Bluetooth playback

● Set up 2 auxiliary send, convenient to expand the device.1 effect send, 1 return.

●100mm long life high analysis push.

● Input sensitivity: microphone: -60dB

● Stereo channel input: -40dB

● Echo send: -20dB

Echo back: -20dB

● Output: Maximum 4V

● SNR S/N: -80dB

● Equalization:

● High frequency: ±15dB/ 10kHz

● Medium frequency MID: ±15dB/ 250KHz ~ 6KHz

Low frequency: ±15dB/ 60Hz

● Maximum output level: 20dBm

● Harmonic distortion T.H.D: ≤ '3d0.1%

● SNR S/N: 80dB

Phantom voltage MIC:48V
